Silicone Neon LED Strip Lights 0816
The Neon LED Strip Lights utilize a one-piece extrusion molding process with Dow-corning silicone, ensuring durability and a seamless design that enhances water resistance. The LED neon is capable of horizontal bending with a minimum diameter of 100mm, providing flexibility for various lighting designs and installations. With a cross-sectional size of 8mm*17mm (width*height), it offers a slim and discreet profile, providing even and consistent illumination without visible hot spots or glare, ensuring aesthetically pleasing lighting effects. Suitable for a broad range of indoor and outdoor lighting applications, including architectural lighting, signage, landscape features, and decorative accents.

Main Features of Silicone Neon LED Strip lights
- Advanced Silicone Material: Made with Dow Chemical SILASTIC™ ET-7021 silicone rubber for superior transparency, strength, and durability.
- Exceptional Resistance: Resistant to salt solutions, acids, alkalis, and UV rays, ensuring performance in harsh environments.
- Uniform Illumination: Unique optical light distribution structure eliminates shadows, providing a smooth and consistent lighting effect.
- Flexible Bending: Horizontal bending with a diameter of 100mm allows for creating various shapes and designs.
- Compact Dimensions: Measuring 8mm (W) x 17mm (H), it’s ideal for sleek, space-saving installations.
- IP67 Waterproof: Suitable for indoor and outdoor applications, offering reliable performance even in harsh environments.
- Multiple Color Options: Available in a wide range of vibrant colors,White, Red, Blue, Green, yellow, Pink, Orange, CCT, and RGB to suit diverse lighting needs.
- Customizable Lengths: Tailor the strip length to your specific requirements for seamless installation.
- Versatile End Caps: Choose from various end cap designs for the perfect finish in any setup.
- Long Lifespan: Built to last with a working life of over 50,000 hours and a reliable 5-year warranty.
Technical Parameter
| Part NO. | SR-NEON-SH0817X |
|---|---|
| LED Type: | Top LED 2835, CRI>90, SDCM<3 |
| Voltage: | DC24V |
| Driver Methord Option: | Constant Current / Constant Voltage |
| Power: | 5w/10w |
| Lumen: | 150-430Lm / m |
| Colors available: | White(2000-6500K), red, blue, green, yellow, Pink, Orange, CCT, RGB |
| Beam angle: | 180 degree |
| Bending Direction: | Side Bending, Horizontal Bending |
| Material: | American Brand Dow-corning Silicone, UV Resistance, Corrosion Resistance |
| Cable Entry: | Front Cable Entry |
| Cable: | UL Listed PVC 20AWG Cable / Silicone 20AWG Cable |
| End Caps Option: | Integrated End Caps / Solder Free End Caps / Silicone Endcaps |
| Accessories: | Mounting Clips, Aluminum profiles, Flexible Aluminum Profiles |
| Dimension: | 8mm*17mm/(W*H) |
| Cuttable Length: | 50mm |
| Working temperature: | -25 – +60℃ |
| IP Rated: | IP67 Rated |
| Working Life: | >50000 working hours |
| Warranty | 5 years warranty |
Dimension
