Free Cutting COB LED Strip Light
The COB LED Strip Light provides high brightness with 512 LEDs/m, a broad 180° viewing angle, and exceptional color accuracy with a CRI over 90. It is energy-efficient at 100lm/W, easy to install with 3M tape, and designed to last over 50,000 hours. Additionally, it offers dot-free and can be freely cut to fit various lighting needs, making it ideal for a range of applications.
Main Features
- High Brightness: Delivers superior illumination with minimal light decay and consistent color.
- High CRI: Greater than CRI90 for true-to-life color rendering；
- Color Consistency: SDCM<3 for uniform color;
- High Light Efficient: Achieves up tp 100lm/W, maximizing energy savings.
- Wide Viewing Angle: Offers a broad 180° viewing angle for even light distribution.
- Easy Installation: Equipped with Orignal 3M tape on the backside for quick and secure mounting.
- Durable: Designed for over 50,000 hours of operation, backed by a 5-year warranty.
- Dot-Free Illumination: Ideal for profile lighting, ensuring smooth, uninterrupted light output.
- Customizable Length: Can be freely cut to fit any lighting needs.
Technical Parameter
| Model | SR-COB-480-5W | SR-COB-480-10W | SR-COB-480-15W |
|---|---|---|---|
| LED Material | Top LED,SDCM<3 | Top LED,SDCM<3 | Top LED,SDCM<3 |
| LED Quantity | 480leds/m | 480leds/m | 480leds/m |
| Voltage | DC12V/24V | DC12V/24V | DC12V/24V |
| Power: | 5W | 10W | 15W |
| Lumen@3000K: | 305Lm | 610Lm | 915Lm |
| Color Temperature: | 2700K-6500K | 2700-6500K | 2700-6500K |
| Light Efficiency: | >61Lm/W | >61Lm/W | >61Lm/W |
| CRI: | >90 | >90 | >90 |
| IP Rated: | IP20/IP65/IP67/IP68 | IP20/IP65/IP67/IP68 | IP20/IP65/IP67/IP68 |
| FPC Width Available | 8mm/10mm | 8mm/10mm | 8mm/10mm |
| Max Length: | 5m /roll | 5m/roll | 5m/roll |
| Unit Cut: | Free cutting | Free Cutting | Free cutting |
| Warranty: | 5 years warranty | 5 years warranty | 5 years warranty |
Dimension
Test Report@ 3000K COB LED Strip Light
