Super Long led streifen
Super Long LED Strip is engineered with constant current technology, enabling stable illumination over lengths up to 20 meters—no voltage drop, no color shift. Built with high-efficiency 2835 LED chips, it delivers exceptional brightness, superior color accuracy (CRI >90), and long-term reliability.
The double-sided 2oz copper FPC enhances conductivity and heat dissipation, ensuring durability even in demanding environments. Ideal for architectural accents, office lighting, commercial spaces, cove lighting, and signage, this strip offers both performance and flexibility.
Equipped with strong 3M adhesive backing, it allows for fast, secure installation on various surfaces. Whether you’re looking for extended length, high brightness, or seamless consistency, this LED strip is the perfect solution for professional lighting projects.
Main Features
- Constant Current Circuit Design: Guarantees stable brightness and color uniformity throughout the entire strip—even over long distances.
- High CRI >90: Delivers accurate, vibrant colors, ideal for commercial, retail, and decorative lighting.
- Extended Run Lengths: Available in 10m, 15m, and 20m continuous rolls with single-end power input—no visible voltage drop.
- Premium Materials: Built with 2oz double-layer FPC for excellent heat dissipation, conductivity, and durability.
- Effortless Installation: Features strong 3M adhesive backing for quick, secure mounting on various surfaces.
- Flexible & Cuttable: Easily bends, twists, and cuts to adapt to complex layouts and custom applications.
- Custom Lengths Available: Supports 10–20m continuous runs tailored to long-distance installations.
Technical Parameter
| Part NO | SR-CC-60W2835 | SR-CC-90W2835 | SR-CC-120W2835 |
|---|---|---|---|
| LED Type: | 2835 SMD LED | 2835 SMD LED | 2835 SMD LED |
| LED Qty/m: | 60leds/m | 90leds/m | 120leds/m |
| CRI: | >90 | >90 | >90 |
| SDCM: | <3 | <3 | <3 |
| Voltage: | DC24V | DC36V | DC24V |
| Power: | 8.5W/10.5/12.5W | 7.2W | 10/12W |
| PCB Width: | 10/12mm | 12mm | 10/12mm |
| Lumen@3000K: | 1090Lm/m | 700Lm/m | 910-1080Lm/m |
| Colors: | WW/NW/CW | WW/NW/CW | WW/NW/CW |
| White Color Tempearture: | 2700-6500K | 2700-6500K | 2700-6500K |
| View angle: | 120° | 120° | 120° |
| Cut Unit: | 100mm | 100mm | 50mm |
| Max running Length: | 10/15/20 meters | 30 meters | 10/15meters |
| Connection Wire: | 20AWG | 20AWG | 20AWG |
| Working Temperature: | -10° C –+45° C | -10° C — +45° C | -10° C – +45° C |
| IP Rated: | IP20/IP65/IP67/IP68 | IP20/IP65/IP67/IP68 | IP20/IP65/IP67/IP68 |
| Warranty: | 5 years warranty | 5 years warranty | 5 years warranty |
Dimension
